KMY bearing insert bearing Pillow Block bearing house SY508M

Bolt Size: M16 Bearing No: SY508M Basic Load (Cr): 71.6 KN
Quantity:

KMY bearing insert bearing Pillow Block bearing house SY508M

insert bearing Pillow Block bearing house SY508M details:


This is the most common type of mounted ball unit. The rib at the bottom of the housing mounting section provides for a robust unit that can withstand great loads from any direction. Mounted units with cast steel housings are also available in this series, and are used for applications with severe loading and shock load conditions. Tapered-bore style units are offered individually and adapters are sold separately.

· Item:SY508M Bearing

· Type: Mounted Ball Bearing

· Shaft Dia: 55mm

· Bolt Size: M16

· Bearing No: SY508M

· Basic Load (Cr): 71.6 KN

· Basic Load (Cor): 45 KN

· Quantity: One Bearing


Dimensions (mm)

d

H

L

A

J

N

N1

H1

H2

L1

S

55

80

310

80

236

20

38

27

158

90

25


insert bearing Pillow Block bearing house SY508M specification

bearing name:

SY508M bearing

Brand model :

SY508M

outer diameter D :

66 mm

diameter d :

55 mm

thickness B :

310 mm

category:

Insert ball bearings with a seat specifications

brand:

SKF SY508M

Remark:

SY508M bearing



if you are interested in UCP311 and some details of its properties, Please contact Email for any inquiries,We are professionally provides you the UCP311 products , UCP311 is widely used in the metallurgy, railway, papermaking, cement, engineering machinery, power, transmission equipment, machine toos, automotive, aerospace industry.


insert bearing Pillow Block bearing house SY508M :

Product Description

(1)structure: The pillow block ball bearings are composed of a single row deep groove ball bearings with seals at both sides and spherical outside surface, and a housing, suitable for simple support.
(2)Usage: Widely used in varieties of mechanical equipment, especially for agricultural, metallurgical, textile and printing machinery.
(3)Material: GCr15, GCR11, EN5100

We can supply Pillow Block Bearing
UCP:
UCP201, UCP202, UCP203, UCP204, UCP205, UCP206, UCP207,
UCP208, UCP209, UCP210, UCP211, UCP212, UCP213, UCP214
UCP215, UCP216, UCP217, UCP218, UCP305, UCP306, UCP307, UCP308, UCP309, UCP310, UCP311, UCP312, UCP313, UCP314, UCP315, UCP316, UCP317, UCP318, UCP319

insert bearing Pillow Block bearing house SY508M feature:

Introduction:Pillow block bearing units have various types of perfect sealing devices and can operate satisfactorily under hard working conditions, especially for machines operated in dusty or muddy surroundings.

1)Pillow block a are most extensively used among the bearing units:UCP,UCPE,UCAK and SBLP,SBLLP.

These types are fixed to the shafts by means of the setscrews prepared in the innerring.


2)NAP,SALP and SALLP types are fixed to the shafts by the setscrews prepared in the eccentric locking collor.


Pillow Block bearing house SY508M catalogue:


Bearing Unit No.

Shaftr Dia d (mm)

Dimensions (mm)

Bolt Used (mm)

Bearing No.

Housing No.

Weight (kg)

h

a

e

b

S2

S1

g

w

Bi

n

UCP305

25

45

175

132

45

20

17

16

85

38

15

M14

UCP305

P 305

1.6

UCP306

30

50

180

140

50

20

17

18

95

43

17

M14

UCP306

P 306

2.1

UCP307

35

56

210

160

56

25

17

20

106

48

19

M14

UCP307

P 307

2.8

UCP308

40

60

220

170

60

27

17

22

116

52

19

M14

UCP308

P 308

3.6

UCP309

45

67

245

190

67

30

20

24

129

57

22

M16

UCP309

P 309

4.7

UCP310

50

75

275

212

75

35

20

27

143

61

22

M16

UCP310

P 310

6.4

UCP311

55

80

310

236

80

38

20

30

154

66

25

M16

UCP311

P 311

7.8

UCP312

60

85

330

250

85

38

25

32

165

71

26

M20

UCP312

P 312

9.4

UCP313

65

90

340

260

90

38

25

35

176

75

30

M20

UCP313

P 313

10.3

UCP314

70

95

360

280

90

40

27

35

187

78

33

M22

UCP314

P 314

11.9

UCP315

75

100

380

290

100

40

27

35

198

82

32

M22

UCP315

P 315

14.5

UCP316

80

106

400

300

110

40

27

40

210

86

34

M22

UCP316

P 316

17.1

UCP317

85

112

420

320

110

45

33

40

220

96

40

M27

UCP317

P 317

19.2

UCP318

90

118

430

330

110

45

33

45

235

96

40

M27

UCP318

P 318

21.1

UCP319

95

125

470

360

120

50

36

45

250

103

41

M30

UCP319

P 319

28.2

UCP320

100

140

490

380

120

50

36

50

275

108

42

M30

UCP320

P 320

34.8

UCP322

110

150

520

400

140

55

40

50

296

117

46

M33

UCP322

P 322

43.2

UCP324

120

160

570

450

140

55

40

50

316

126

51

M33

UCP324

P 324

54

UCP326

130

180

600

480

140

55

40

50

355
