KMY bearing insert bearing Pillow Block bearing house H4090
insert bearing Pillow Block bearing house H4090 details:
This is the most common type of mounted ball unit. The rib at the bottom of the housing mounting section provides for a robust unit that can withstand great loads from any direction. Mounted units with cast steel housings are also available in this series, and are used for applications with severe loading and shock load conditions. Tapered-bore style units are offered individually and adapters are sold separately.
· Item:H4090 Bearing
· Type: Mounted Ball Bearing
· Shaft Dia: 55mm
· Bolt Size: M16
· Bearing No: H4090
· Basic Load (Cr): 71.6 KN
· Basic Load (Cor): 45 KN
· Quantity: One Bearing
Dimensions (mm) | ||||||||||
d | H | L | A | J | N | N1 | H1 | H2 | L1 | S |
55 | 80 | 310 | 80 | 236 | 20 | 38 | 27 | 158 | 90 | 25 |
insert bearing Pillow Block bearing house H4090 specification
bearing name: | H4090 bearing |
Brand model : | SY2TF |
outer diameter D : | 66 mm |
diameter d : | 55 mm |
thickness B : | 310 mm |
category: | Insert ball bearings with a seat specifications |
| |
Remark: | H4090 bearing |
|
|
|
|
if you are interested in UCP311 and some details of its properties, Please contact Email for any inquiries,We are professionally provides you the UCP311 products , UCP311 is widely used in the metallurgy, railway, papermaking, cement, engineering machinery, power, transmission equipment, machine toos, automotive, aerospace industry.
insert bearing Pillow Block bearing house H4090 :
Product Description
(1)structure: The pillow block ball bearings are composed of a single row deep groove ball bearings with seals at both sides and spherical outside surface, and a housing, suitable for simple support.
(2)Usage: Widely used in varieties of mechanical equipment, especially for agricultural, metallurgical, textile and printing machinery.
(3)Material: GCr15, GCR11, EN5100
We can supply Pillow Block Bearing
UCP:
UCP201, UCP202, UCP203, UCP204, UCP205, UCP206, UCP207,
UCP208, UCP209, UCP210, UCP211, UCP212, UCP213, UCP214
UCP215, UCP216, UCP217, UCP218, UCP305, UCP306, UCP307, UCP308, UCP309, UCP310, UCP311, UCP312, UCP313, UCP314, UCP315, UCP316, UCP317, UCP318, UCP319
insert bearing Pillow Block bearing house H4090 feature:
Introduction:Pillow block bearing units have various types of perfect sealing devices and can operate satisfactorily under hard working conditions, especially for machines operated in dusty or muddy surroundings.
1)Pillow block a are most extensively used among the bearing units:UCP,UCPE,UCAK and SBLP,SBLLP.
These types are fixed to the shafts by means of the setscrews prepared in the innerring.
2)NAP,SALP and SALLP types are fixed to the shafts by the setscrews prepared in the eccentric locking collor.
Pillow Block bearing house H4090 catalogue:
Bearing Unit No. | Shaftr Dia d (mm) | Dimensions (mm) | Bolt Used (mm) | Bearing No. | Housing No. | Weight (kg) | |||||||||
h | a | e | b | S2 | S1 | g | w | Bi | n | ||||||
UCP305 | 25 | 45 | 175 | 132 | 45 | 20 | 17 | 16 | 85 | 38 | 15 | M14 | UCP305 | P 305 | 1.6 |
UCP306 | 30 | 50 | 180 | 140 | 50 | 20 | 17 | 18 | 95 | 43 | 17 | M14 | UCP306 | P 306 | 2.1 |
UCP307 | 35 | 56 | 210 | 160 | 56 | 25 | 17 | 20 | 106 | 48 | 19 | M14 | UCP307 | P 307 | 2.8 |
UCP308 | 40 | 60 | 220 | 170 | 60 | 27 | 17 | 22 | 116 | 52 | 19 | M14 | UCP308 | P 308 | 3.6 |
UCP309 | 45 | 67 | 245 | 190 | 67 | 30 | 20 | 24 | 129 | 57 | 22 | M16 | UCP309 | P 309 | 4.7 |
UCP310 | 50 | 75 | 275 | 212 | 75 | 35 | 20 | 27 | 143 | 61 | 22 | M16 | UCP310 | P 310 | 6.4 |
UCP311 | 55 | 80 | 310 | 236 | 80 | 38 | 20 | 30 | 154 | 66 | 25 | M16 | UCP311 | P 311 | 7.8 |
UCP312 | 60 | 85 | 330 | 250 | 85 | 38 | 25 | 32 | 165 | 71 | 26 | M20 | UCP312 | P 312 | 9.4 |
UCP313 | 65 | 90 | 340 | 260 | 90 | 38 | 25 | 35 | 176 | 75 | 30 | M20 | UCP313 | P 313 | 10.3 |
UCP314 | 70 | 95 | 360 | 280 | 90 | 40 | 27 | 35 | 187 | 78 | 33 | M22 | UCP314 | P 314 | 11.9 |
UCP315 | 75 | 100 | 380 | 290 | 100 | 40 | 27 | 35 | 198 | 82 | 32 | M22 | UCP315 | P 315 | 14.5 |
UCP316 | 80 | 106 | 400 | 300 | 110 | 40 | 27 | 40 | 210 | 86 | 34 | M22 | UCP316 | P 316 | 17.1 |
UCP317 | 85 | 112 | 420 | 320 | 110 | 45 | 33 | 40 | 220 | 96 | 40 | M27 | UCP317 | P 317 | 19.2 |
UCP318 | 90 | 118 | 430 | 330 | 110 | 45 | 33 | 45 | 235 | 96 | 40 | M27 | UCP318 | P 318 | 21.1 |
UCP319 | 95 | 125 | 470 | 360 | 120 | 50 | 36 | 45 | 250 | 103 | 41 | M30 | UCP319 | P 319 | 28.2 |
UCP320 | 100 | 140 | 490 | 380 | 120 | 50 | 36 | 50 | 275 | 108 | 42 | M30 | UCP320 | P 320 | 34.8 |
UCP322 | 110 | 150 | 520 | 400 | 140 | 55 | 40 | 50 | 296 | 117 | 46 | M33 | UCP322 | P 322 | 43.2 |
UCP324 | 120 | 160 | 570 | 450 | 140 | 55 | 40 | 50 | 316 | 126 | 51 | M33 | UCP324 | P 324 | 54 |
UCP326 | 130 | 180 | 600 | 480 | 140 | 55 | 40 | 50 | 355 |
|
|
|
|
|
|
