Product data of NJ 240
Inside diameter= 200 mm
Outside Diameter=360 mm
Width= 58 mm
Weight= 29 kg
Basic dynamic load rating= 850 kN
Basic static load rating= 1020 kN
Fatigue load limit= 100 kN
Reference speed= 1900 r/min
Limiting speed= 2800 r/min
Angle ring:HJ 240 EC
NJ 240 ECMA Cylindrical roller bearings with machined brass cageare used as no-nlocating bearings.
They has two integral flanges on the out rings and no flanges on the inner ring Axial displacement of the shaft with respect to the housing can be accommodated in both directions within
the bearing itself.
