234440M.SP
8482102000
Thrust ball bearings 234440M.SP
Technical data of 234440M.SP
ID: 200 mm
OD: 310 mm
Width: 132 mm
Weight: 30.9 kg
Basic dynamic load rating: 285 kN
Basic static load rating: 1060 kN
Fatigue limit load: 59 kN
Limiting speed for grease lub.: 1800 rpm
Limiting speed for oil lub.: 2600 rpm
Solid brass cage, ball-guided
Restricted tolerance class SP
Part stocklist of our Axial Angular contact ball bearings
Part Thrust ball bearings catalogue
bearing Part No. | ID mm | OD mm | Width mm |
234406-M-SP | 30 | 55 | 32 |
234407-M-SP | 35 | 62 | 34 |
234408-M-SP | 40 | 68 | 36 |
234409-M-SP | 45 | 75 | 38 |
234410-M-SP | 50 | 80 | 38 |
234411-M-SP | 55 | 90 | 44 |
234412-M-SP | 60 | 95 | 44 |
234413-M-SP | 65 | 100 | 44 |
234414-M-SP | 70 | 110 | 48 |
234415-M-SP | 75 | 115 | 48 |
234416-M-SP | 80 | 125 | 54 |
234417-M-SP | 85 | 130 | 54 |
234418-M-SP | 90 | 140 | 60 |
234419-M-SP | 95 | 145 | 60 |
234420-M-SP | 100 | 150 | 60 |
234421-M-SP | 105 | 160 | 66 |
234422-M-SP | 110 | 170 | 72 |
234424-M-SP | 120 | 180 | 72 |
234426-M-SP | 130 | 200 | 84 |
234428-M-SP | 140 | 210 | 84 |
234430-M-SP | 150 | 225 | 90 |
234432-M-SP | 160 | 240 | 96 |
234434-M-SP | 170 | 260 | 108 |
234436-M-SP | 180 | 280 | 120 |
234438-M-SP | 190 | 290 | 120 |
234440-M-SP | 200 | 310 | 132 |
234444-M-SP | 220 | 340 | 144 |
234448-M-SP | 240 | 360 | 144 |
234452-M-SP | 260 | 400 | 164 |
234456-M-SP | 280 | 420 | 164 |
234460-M-SP | 300 | 460 | 190 |
234464-M-SP | 320 | 480 | 190 |
234468-M-SP | 340 | 520 | 212 |
234472-M-SP | 360 | 540 | 212 |
234476-M-SP | 380 | 560 | 212 |
234480-M-SP | 400 | 600 | 236 |
