Thrust ball bearing 51140 MP
Quick Details
Structure: Thrust
Type: Ball
Brand Name: KMY
Bore Size: 200 mm
Outside Diameter: 250 mm
Model Number: 51140 MP
Precision Rating: P0, P6, P5, P4, P2
Seals Type: OPEN
Number of Row: Single Row
Place of Origin: Shandong, China (Mainland)
Width: 37mm
Basic dynamic load rating: 232KN
Basic static load rating: 965KN
Fatigue load limit: 31KN
Limiting speed: 1640rpm
certificate: ISO 9001:2000 , SGS , BV
clearance: C0 , C2 , C3 , C1 , C4 , C5 , C6
commitment: high quality high precision waterproof bearing
main market: Eastern Europe,Southeast Asia, South America
Thrust ball bearing 51140 MP comprise of shaft location washers, housing locating washers and brass cage assemblies. The bearings are not self-retaining; the ball and cage assembly can be fitted separatley. Bearings of series 511 & 512 have a flat housing location washer. They do not permit angular misalignment or slewing between the shaft and the housing.
Product data of Thrust ball bearing 51140 MP
d=200 mm
D=250 mm
T=37 mm
C=170 kN Basic dynamic load rating, axial
C0=655 kN Basic static load rating, axial
Cua=22.7 kN Fatigue load limit
nG=1400 r/min Limiting speed
m=4.12 kg Mass
Bearing interchangeble reference for 51140 MP
bearing 51140M
NSK bearing 51140M
NTN bearing 51140M
bearing 51140M
KOYO bearing 51140R
More bearing cross reference and interchange information, Please contact us.
If you want to know more about our products, please feel free to contact me. You may also visit our online company introduction which includes our latest product line. We will be happy to give you a quotation upon receipt of your detailed requirements.
I am looking forward to receiving your enquires soon. And I hope to have the opportunity to cooperate with you in the future.
