NJ2230-E-M1-C3 Cylindrical roller bearings are semi-locating bearings. separable, and with brass cage. Semi-locating bearings can support not only high radial forces but also axial forces in one direction and can therefore guide shafts axially in one direction. They act as non-locating bearings in the opposite direction. The bearings have two ribs on the outer ring and one rib on the inner ring.

Technical data of NJ2230-E-M1-C3 Cylindrical roller bearings

ID: 150 mm

OD: 270 mm

Width: 73 mm

Weight; 18.9 kg

Basic dynamic load rating: 780 kN

Basic static load rating: 970 kN

Fatigue limit load: 150 kN

Limiting speed: 3950 rpm

Reference speed: 1870 rpm
