This is the most basic and most widely used type of tapered roller bearing. It consists of two main separable parts: the cone(inner ring) assembly and the cup (outer ring). It is typically mounted in opposing pairs on a shaft.Mainly engineered bearings.
Application Engineered bearings.General Industrial Machinery, Automotive, Construction Equipment, Trailers Bore Size 4.3125" Cone Width 0.8440" Cup Width 0.6250" Material Steel Outer Diameter 6.2500" Style Cone & Cup Set Type Tapered Roller Bearing Width 0.9063" Product Weight 2.88
Bearing number
37431A/37625
Size (mm)
109.538x158.75x23.02
Brand
Timken
B
21,438 mm
C
15,875 mm
R
5 mm
r
3,3 mm
Weight
1,3 Kg
This is the most basic and most widely used type of tapered roller bearing. It consists of two main separable parts: the cone(inner ring) assembly and the cup (outer ring). It is typically mounted in opposing pairs on a shaft.Mainly engineered bearings.
Application Engineered bearings.General Industrial Machinery, Automotive, Construction Equipment, Trailers Bore Size 4.3125" Cone Width 0.8440" Cup Width 0.6250" Material Steel Outer Diameter 6.2500" Style Cone & Cup Set Type Tapered Roller Bearing Width 0.9063" Product Weight 2.88
