| Quantity: | |
|---|---|
Bore Size: 0 - 60 mm
Outside Diameter: 0 - 110 mm
Model Number: BS2-2212CS
Width: 34mm
Description: Sealed BS2-2212-2CS bearing
1. Application:
1)These bearing are widely used in automobile, electrical.
(Home appliances, electric tools, fitness equipment, motors, medical devices, motorbikes, textile machines)
2)equipment,instrument,building machinery,rolling stock agricultural machinery and various specialized machineries.
2. Standard sealed bearing models:
| Principal dimension(mm) | Bearing number | Basic Load Rating(KN) | Speed(rpm) | ||||
| d | D | B | Dynamic Cr | Static Cor | reference | Limited | |
| 25 | 52 | 23 | BS2-2205-2CS/VT143 * | 49,9 | 44.0 |
| 3600 |
| 30 | 62 | 25 | BS2-2206-2CS/VT143 * | 66,1 | 60.0 |
| 2800 |
| 35 | 72 | 28 | BS2-2207-2CS/VT143 * | 88,8 | 85.0 |
| 2400 |
| 40 | 80 | 28 | BS2-2208-2CS/VT143 * | 98,5 | 90.0 |
| 2200 |
| 40 | 80 | 28 | BS2-2208-2CSK/VT143 * | 98,5 | 90.0 |
| 2200 |
| 40 | 90 | 38 | BS2-2308-2CS/VT143 * | 155.0 | 140.0 |
| 1900 |
| 45 | 85 | 28 | BS2-2209-2CS/VT143 * | 104.0 | 98.0 |
| 2000 |
| 45 | 85 | 28 | BS2-2209-2CSK/VT143 * | 104.0 | 98.0 |
| 2000 |
| 45 | 100 | 42 | BS2-2309-2CS/VT143 * | 190.0 | 183.0 |
| 1500 |
| 50 | 90 | 28 | BS2-2210-2CS/VT143 * | 107.0 | 108.0 |
| 1900 |
| 50 | 90 | 28 | BS2-2210-2CSK/VT143 * | 107.0 | 108.0 |
| 1900 |
| 50 | 110 | 45 | BS2-2310-2CS/VT143 * | 228.0 | 224.0 |
| 1400 |
| 55 | 100 | 31 | BS2-2211-2CS/VT143 * | 129.0 | 127.0 |
| 1700 |
| 55 | 100 | 31 | BS2-2211-2CSK/VT143 * | 129.0 | 127.0 |
| 1700 |
| 55 | 120 | 49 | BS2-2311-2CS/VT143 * | 280.0 | 280.0 |
| 1400 |
| 60 | 110 | 34 | BS2-2212-2CS/VT143 * | 159.0 | 166.0 |
| 1600 |
| 60 | 110 | 34 | BS2-2212-2CSK/VT143 * | 159.0 | 166.0 |
| 1600 |
Bore Size: 0 - 60 mm
Outside Diameter: 0 - 110 mm
Model Number: BS2-2212CS
Width: 34mm
Description: Sealed BS2-2212-2CS bearing
1. Application:
1)These bearing are widely used in automobile, electrical.
(Home appliances, electric tools, fitness equipment, motors, medical devices, motorbikes, textile machines)
2)equipment,instrument,building machinery,rolling stock agricultural machinery and various specialized machineries.
2. Standard sealed bearing models:
| Principal dimension(mm) | Bearing number | Basic Load Rating(KN) | Speed(rpm) | ||||
| d | D | B | Dynamic Cr | Static Cor | reference | Limited | |
| 25 | 52 | 23 | BS2-2205-2CS/VT143 * | 49,9 | 44.0 |
| 3600 |
| 30 | 62 | 25 | BS2-2206-2CS/VT143 * | 66,1 | 60.0 |
| 2800 |
| 35 | 72 | 28 | BS2-2207-2CS/VT143 * | 88,8 | 85.0 |
| 2400 |
| 40 | 80 | 28 | BS2-2208-2CS/VT143 * | 98,5 | 90.0 |
| 2200 |
| 40 | 80 | 28 | BS2-2208-2CSK/VT143 * | 98,5 | 90.0 |
| 2200 |
| 40 | 90 | 38 | BS2-2308-2CS/VT143 * | 155.0 | 140.0 |
| 1900 |
| 45 | 85 | 28 | BS2-2209-2CS/VT143 * | 104.0 | 98.0 |
| 2000 |
| 45 | 85 | 28 | BS2-2209-2CSK/VT143 * | 104.0 | 98.0 |
| 2000 |
| 45 | 100 | 42 | BS2-2309-2CS/VT143 * | 190.0 | 183.0 |
| 1500 |
| 50 | 90 | 28 | BS2-2210-2CS/VT143 * | 107.0 | 108.0 |
| 1900 |
| 50 | 90 | 28 | BS2-2210-2CSK/VT143 * | 107.0 | 108.0 |
| 1900 |
| 50 | 110 | 45 | BS2-2310-2CS/VT143 * | 228.0 | 224.0 |
| 1400 |
| 55 | 100 | 31 | BS2-2211-2CS/VT143 * | 129.0 | 127.0 |
| 1700 |
| 55 | 100 | 31 | BS2-2211-2CSK/VT143 * | 129.0 | 127.0 |
| 1700 |
| 55 | 120 | 49 | BS2-2311-2CS/VT143 * | 280.0 | 280.0 |
| 1400 |
| 60 | 110 | 34 | BS2-2212-2CS/VT143 * | 159.0 | 166.0 |
| 1600 |
| 60 | 110 | 34 | BS2-2212-2CSK/VT143 * | 159.0 | 166.0 |
| 1600 |
