· Inherently self-aligning and very robust
· Two rows of rollers make the bearings able to carry heavy loads
· Invented by FAG and refined over the years, the present FAG range of spherical roller bearings includes a wide range of sizes of several ISO dimension series
· Oil grooves and holes in outer ring
| Bore Diameter: | 30 mm |
| Outside Diameter: | 62 mm |
| Overall Width: | 20 mm |
| Bore Type: | Round |
| Outer Ring Type: | Not Split |
| Lubrication Hole Type: | Lubrication Groove & Holes |
| Internal Clearance: | C0 |
| Closure Type: | Open |
| Operating Temperature Range: | Maximum of +390 °F |
| Dynamic Load Capacity: | 64 kN |
| Static Load Capacity: | 60 kN |
| Maximum RPM: | 14000 RPM |
| Cage Material: | Steel |
| Bearing Material: | Steel |
| Cage Type: | Inner Ring Guided |
| Precision Rating: | Not Rated |
| Finish/Coating: | Uncoated |
| Outer Ring Width: | 20 mm |
| Fillet Radius: | 1 mm |
| Series: | 222 |
