| Quantity: | |
|---|---|
Bore Size: 0 - 55 mm
Outside Diameter: 0 - 100 mm
Model Number: 20211M
Description: Spherical Roller bearing 20211M
Width: 21mm
Application:
1)These bearing are widely used in automobile, electrical.
(Home appliances, electric tools, fitness equipment, motors, medical devices, motorbikes, textile machines)
2)equipment,instrument,building machinery,rolling stock agricultural machinery and various specialized machineries.
Standard models of 20200 series spherical roller bearings:
| Bearing Model | size(mm) | Load rating | Lubrication | Weight | |||||
|
|
| KN |
| kg | |||||
| New model | d | D | B | rmin | Cr | Cor |
|
| |
|
|
|
|
|
|
|
|
| rmin |
|
| 20200 series | |||||||||
| 20205M | 25 | 52 | 15 | 1 | 24 | 25 | 6700 | 0.13 | |
| 20206M | 30 | 62 | 16 | 1 | 27.5 | 28.5 | 5600 | 0.21 | |
| 20207M | 35 | 72 | 17 | 1.1 | 40.5 | 43 | 4800 | 0.30 | |
| 20208M | 40 | 80 | 18 | 1.1 | 49 | 53 | 4300 | 0.39 | |
| 20209M | 45 | 85 | 19 | 1.1 | 52 | 57 | 4000 | 0.43 | |
| 20210M | 50 | 90 | 20 | 1.1 | 58.5 | 68 | 3600 | 0.49 | |
| 20211M | 55 | 100 | 21 | 1.5 | 73.5 | 85 | 3400 | 0.64 | |
| 20212M | 60 | 110 | 22 | 1.5 | 85 | 100 | 3200 | 0.82 | |
| 20213M | 65 | 120 | 23 | 1.5 | 95 | 116 | 3000 | 1.07 | |
| 20214M | 70 | 125 | 24 | 1.5 | 106 | 134 | 2800 | 1.17 | |
| 20215M | 75 | 130 | 25 | 1.5 | 112 | 143 | 2800 | 1.28 | |
| 20216M | 80 | 140 | 26 | 2 | 125 | 163 | 2600 | 1.58 | |
| 20217M | 85 | 150 | 28 | 2 | 156 | 200 | 2400 | 2.22 | |
| 20218M | 90 | 160 | 30 | 2 | 173 | 220 | 2000 | 2.72 | |
| 20219M | 95 | 170 | 32 | 2.1 | 208 | 265 | 1900 | 3.19 | |
| 20220M | 100 | 180 | 34 | 2.1 | 224 | 290 | 1900 | 3.96 | |
