Self-aligning ball bearing with adapter sleeve 1215 K+H215
H 215 Adapter sleeves are used to secure 1215 K Self-aligning ball bearings with a tapered bore onto cylindrical shaft seats Adapter sleeves H 215 do not require axial locating devices on the shaft. They facilitate 1215 K Self-aligning ball bearing mounting and dismounting and often simplify bearing arrangement design.
Product data of 1215 K + H 215 Self-aligning ball bearings on an adapter sleeve
Shaft diameter=65 mm
Outside diameter=130 mm
Width=25 mm
Weight=2.0 kg
Basic dynamic load rating=39 kN
Basic static load rating=15.6 kN
Fatigue load limit=0.8 kN
Reference speed=10000 rpm
Limiting speed=6700 rpm
| 1204 EKTN9 + H 204 | 2309 EKTN9 + H 2309 | 2315 KM + H 2315 |
| 1205 EKTN9 + H 205 | 1210 EKTN9 + H 210 | 1216 K + H 216 |
| 2205 E-2RS1 KTN9 + H 305 C | 2210 E-2RS1 KTN9 + H 310 C | 2216 EKTN9 + H 316 |
| 2205 EKTN9 + H 305 | 2210 EKTN9 + H 310 | 1316 K + H 316 |
| 1305 EKTN9 + H 305 | 1310 EKTN9 + H 310 | 2316 K + H 2316 |
| 1206 EKTN9 + H 206 | 2310 K + H 2310 | 2316 KM + H 2316 |
| 2206 E-2RS1 KTN9 + H 306 C | 1211 EKTN9 + H 211 | 1217 K + H 217 |
| 2206 EKTN9 + H 306 | 2211 E-2RS1 KTN9 + H 311 C | 2217 K + H 317 |
| 1306 EKTN9 + H 306 | 2211 EKTN9 + H 311 | 1317 K + H 317 |
| 2306 K + H 2306 | 1311 EKTN9 + H 311 | 2317 KM + H 2317 |
| 1207 EKTN9 + H 207 | 2311 K + H 2311 | 1218 K + H 218 |
| 2207 E-2RS1 KTN9 + H 307 C | 1212 EKTN9 + H 212 | 2218 K + H 318 |
| 2207 EKTN9 + H 307 | 2212 E-2RS1 KTN9 + H 312 C | 1318 K + H 318 |
| 1307 EKTN9 + H 307 | 2212 EKTN9 + H 312 | 2318 KM + H 2318 |
| 2307 EKTN9 + H 2307 | 1312 EKTN9 + H 312 | 1219 K + H 219 |
| 2307 KM+ H 2307 | 2312 K + H 2312 | 2219 KM + H 319 |
| 1208 EKTN9 + H 208 | 1213 EKTN9 + H 213 | 1319 K + H 319 |
| 2208 E-2RS1 KTN9 + H 308 C | 2213 E-2RS1 KTN9 + H 313 C | 1220 K + H 220 |
| 2208 EKTN9 + H 308 | 2213 EKTN9 + H 313 | 2220 KM + H 320 |
| 1308 EKTN9 + H 308 | 1313 EKTN9 + H 313 | 1320 K + H 320 |
| 2308 EKTN9 + H 2308 | 2313 K + H 2313 | 2320 KM + H 2320 |
| 1209 EKTN9 + H 209 | 1215 K + H 215 | 1222 K + H 222 |
| 2209 E-2RS1 KTN9 + H 309 C | 2215 EKTN9 + H 315 | 2222 KM + H 322 |
| 2209 EKTN9 + H 309 | 1315 K + H 315 | 1322 KM + H 322 |
| 1309 EKTN9 + H 309 | 2315 K + H 2315 | 1224 KM + H 3024 |
