7330 B/DB
SNR Angular Contact Ball Bearings 7330 B/DB
Item: Angular Contact Ball Bearing
Type: Single Row Standard
Contact Angle (Degree): 40 Degrees
Bore Dia.: 150mm
Outside Dia.: 320mm
Width: 65mm
Standard Preload (lbs. ): 122
Standard Preload: (N)540
Max.: RPM2400
Dynamic Load Capacity (Lb. ): 74, 600
Dynamic Load Capacity (N): 332, 000
Static Load Capacity (Lb. ): 82, 100
Static Load Capacity (N): 365, 100
ABEC Tolerance3
Temp. Range: (F)-40 Degrees to 212 Degrees
Cage Material: Machined Brass
LubricationMT: 47 Grease
Part Angular contact ball bearings catalogue
Part Number | d mm | D mm | B mm |
7301-B-JP | 12 | 37 | 12 |
7301-B-TVP | 12 | 37 | 12 |
7302-B-TVP | 15 | 42 | 13 |
7302-B-JP | 15 | 42 | 13 |
7303-B-TVP | 17 | 47 | 14 |
7303-B-JP | 17 | 47 | 14 |
7304-B-JP | 20 | 52 | 15 |
7304-B-TVP | 20 | 52 | 15 |
7305-B-TVP | 25 | 62 | 17 |
7305-B-JP | 25 | 62 | 17 |
7306-B-TVP | 30 | 72 | 19 |
7306-B-JP | 30 | 72 | 19 |
7307-B-TVP | 35 | 80 | 21 |
7307-B-JP | 35 | 80 | 21 |
7308-B-TVP | 40 | 90 | 23 |
7308-B-JP | 40 | 90 | 23 |
7309-B-JP | 45 | 100 | 25 |
7309-B-TVP | 45 | 100 | 25 |
7310-B-TVP | 50 | 110 | 27 |
7310-B-JP | 50 | 110 | 27 |
7311-B-TVP | 55 | 120 | 29 |
7311-B-JP | 55 | 120 | 29 |
7312-B-JP | 60 | 130 | 31 |
7312-B-TVP | 60 | 130 | 31 |
7313-B-TVP | 65 | 140 | 33 |
7313-B-JP | 65 | 140 | 33 |
7314-B-TVP | 70 | 150 | 35 |
7314-B-JP | 70 | 150 | 35 |
7315-B-TVP | 75 | 160 | 37 |
7315-B-JP | 75 | 160 | 37 |
7316-B-TVP | 80 | 170 | 39 |
7316-B-JP | 80 | 170 | 39 |
7317-B-JP | 85 | 180 | 41 |
7317-B-TVP | 85 | 180 | 41 |
7318-B-TVP | 90 | 190 | 43 |
7318-B-JP | 90 | 190 | 43 |
7319-B-TVP | 95 | 200 | 45 |
7319-B-JP | 95 | 200 | 45 |
7320-B-JP | 100 | 215 | 47 |
7320-B-TVP | 100 | 215 | 47 |
7321-B-MP | 105 | 225 | 49 |
7322-B-TVP | 110 | 240 | 50 |
7322-B-JP | 110 | 240 | 50 |
7324-B-TVP | 120 | 260 | 55 |
7326-B-TVP | 130 | 280 | 58 |
7328-B-MP | 140 | 300 | 62 |
7330-B-MP | 150 | 320 | 65 |
7332-B-MP | 160 | 340 | 68 |
7334-B-MP | 170 | 360 | 72 |
