594/592 Taper Roller Bearing, Single Row, Imperial 95.25x152.40x39.69 - ZKL brand.
Tapered Roller Bearings generally come in two parts - the cone (consisting of the inner ring and roller cage assembly)
and the cup (outer ring). The Part Number for these bearings is comprised of the "Cone Reference / Cup Reference".
These two parts can be mounted separately.
Tapered Roller Bearings are particularly suited to the accommodation of combined radial and axial load
Bore diam. (d) : 95.25 mm
Outside diam. (D) : 152.4 mm
IR width (B) : 36.322 mm
OR width (C) : 30.162 mm
Total width (T) : 39.688 mm
Weight : 2.51 kg
Recommended minimum temperature : -40 ° C
Recommended maximum temperature : 120 ° C
Grease speed limit : 2300 tr/min
Oil speed limit : 3100 tr/min
Sealing : None
Cage : Steel
