Quick Details
Structure: Deep Groove
Type: Ball
Bore Size: 110 mm
Outside Diameter: 200 mm
Model Number: 6220
Precision Rating: P6/P5/P2/P0
Seals Type: Open
Number of Row: Single Row
Place of Origin: Germany
Material:: GCR-15 chrom steel
Application: Machine/motor/generator
Service:: OEM
Cage:: Steel / brass / nylon
Package:: Single Color Box
Width: 38 mm
Guarantee:: 1 year
Inspection:: By PPAP Document
Seals Type:: As request
Deep groove ball bearing series:
| Bearing No. | Boundary dimensions | Basic load ratings (kN) | Limiting speed | Mass | |||||
| mm | Dynamic | Static | rpm | Kg | |||||
| d | D | B | rs min | Cr | Cor | Grease | Oil | ||
| 6200 | 10 | 30 | 9 | 0.6 | 5.1 | 2.38 | 25000 | 30000 | 0.032 |
| 6201 | 12 | 32 | 10 | 0.6 | 6.82 | 3.05 | 22000 | 26000 | 0.035 |
| 6202 | 15 | 35 | 11 | 0.6 | 7.65 | 3.72 | 19000 | 23000 | 0.045 |
| 6203 | 17 | 40 | 12 | 0.6 | 9.58 | 4.78 | 18000 | 21000 | 0.064 |
| 6204 | 20 | 47 | 14 | 1 | 12.8 | 6.65 | 16000 | 18000 | 0.103 |
| 6205 | 25 | 52 | 15 | 1 | 14 | 7.88 | 13000 | 15000 | 0.127 |
| 6206 | 30 | 62 | 16 | 1 | 19.5 | 11.5 | 11000 | 13000 | 0.2 |
| 6207 | 35 | 72 | 17 | 1.1 | 25.5 | 15.2 | 9800 | 11000 | 0.288 |
| 6208 | 40 | 80 | 18 | 1.1 | 29.5 | 18 | 8700 | 10000 | 0.368 |
| 6209 | 45 | 85 | 19 | 1.1 | 31.5 | 20.5 | 7800 | 9200 | 0.416 |
| 6210 | 50 | 90 | 20 | 1.1 | 35 | 23.2 | 7100 | 8300 | 0.463 |
| 6211 | 55 | 100 | 21 | 1.5 | 43.4 | 29.4 | 6400 | 7600 | 0.607 |
| 6212 | 60 | 110 | 22 | 1.5 | 52.4 | 36.2 | 6000 | 7000 | 0.783 |
| 6213 | 65 | 120 | 23 | 1.5 | 57.2 | 40.1 | 5500 | 6500 | 0.99 |
| 6214 | 70 | 125 | 24 | 1.5 | 62.2 | 44.1 | 5100 | 6000 | 1.07 |
| 6215 | 75 | 130 | 25 | 1.5 | 67.4 | 48.3 | 4800 | 5600 | 1.18 |
| 6216 | 80 | 140 | 26 | 2 | 72.7 | 53 | 4500 | 5300 | 1.4 |
| 6217 | 85 | 150 | 28 | 2 | 84 | 61.9 | 4200 | 5000 | 1.79 |
| 6218 | 90 | 160 | 30 | 2 | 96.1 | 71.5 | 4000 | 4700 | 2.15 |
| 6219 | 95 | 170 | 32 | 2.1 | 109 | 81.9 | 3700 | 4400 | 2.62 |
| 6220 | 100 | 180 | 34 | 2.1 | 122 | 93.1 | 3500 | 4200 | 3.14 |
| 6221 | 105 | 190 | 36 | 2.1 | 133 | 105 | 3400 | 4000 | 3.7 |
| 6222 | 110 | 200 | 38 | 2.1 | 144 | 117 | 3200 | 3800 | 4.36 |
| 6224 | 120 | 215 | 40 | 2.1 | 155 | 131 | 2900 | 3400 | 5.15 |
| 6226 | 130 | 230 | 40 | 3 | 167 | 146 | 2700 | 3100 | 5.82 |
| 6228 | 140 | 250 | 42 | 3 | 166 | 150 | 2500 | 2900 | 7.57 |
| 6230 | 150 | 270 | 45 | 3 | 176 | 168 | 2300 | 2700 | 9.41 |
| 6232 | 160 | 290 | 48 | 3 | 185 | 186 | 2100 | 2500 | 11.7 |
| 6234 | 170 | 310 | 52 | 4 | 212 | 223 | 2000 | 2400 | 14.5 |
| 6236 | 180 | 320 | 52 | 4 | 227 | 241 | 1900 | 2200 | 15.1 |
| 6238 | 190 | 340 | 55 | 4 | 255 | 281 | 1800 | 2100 | 18.2 |
| 6240 | 200 | 360 | 58 | 4 | 269 | 310 | 1700 | 2000 | 21.6 |
| 6244 | 220 | 400 | 65 | 4 | 297 | 365 | 1500 | 1800 | 30 |
Ball Bearing 6222 Cage:
deep groove ball bearings 6222 use pressed steel cage or solid brass cage.
Application of ball bearing 6222 c3:
Deep groove ball bearing 6222 can be used in transmission, instrumentation ,
electrical , household appliances, internal combustion engines, transport vehicles ,
agricultural machinery, construction machinery , engineering machinery , roller skate
style , yo-yo , etc.
