| Quantity: | |
|---|---|
Quick Details
Structure: Angular Contact
Type: Ball
Brand Name: KMY/OEM/NSK
Bore Size: 85 mm
Outside Diameter: 150 mm
Model Number: 7217
Precision Rating: P2 P4 P5 P6
Seals Type: open/zz/2rs
Number of Row: Single Row
Place of Origin: China (Mainland)
Certificate:: ISO9001:2000
Service:: OEM
Quality:: High quality
Sample:: available
Description of bearing 7217:
| Product name | ball bearing 7217 |
| Brand name | KMY/OEM |
| Original Packing | (a)Neutral package & wooden package |
| Precision | P2/P4/P5/P6/P0 |
| Material | GCR-15 chrom steel,Bearing Steel |
| Quality standard | ISO9001:2000 |
| Delivery date | Within 5 working days or according to you request |
| Payment terms | A:100% T/T in advance at sight B:30%T/T in advance.70% against copy of B/L |
| Application | Sugar mill;Plastic machinery;Papermaking machinery;Oil industry; Instrument;Steel industry Automobiles;Air blower;Rolling mill; Home application;and so on. |
| Features | these bearings are featured by the extremely big axial load carrying capacityand meanwhile,they can also carry cetain radial load |
| Package | single box/industrial standard packing/single carton/ according to buyers requirement |
| Cage Material | Bearing steel/brass |
| Main market | Mideast;Canada;Southeast Asia;South America and other countries all over the world |
| Company name | Jinan Kaiming Bearing CO.,LTD |
Apllication of ball bearing 7217:
Machine tool spindles, high-frequency motors, gas turbine, centrifugal separator,
small car front wheel and the differential pinion shaft.
Angular contact ball bearing list:
| Bearing | b | D | B | Cr | Cor | Weight |
| (mm) | (mm) | (mm) | (kN) | (kN) | (kg) | |
| 7200C | 10 | 30 | 9 | 5 | 2.35 | 0.031 |
| 7201C | 12 | 32 | 10 | 7.9 | 3.85 | 0.038 |
| 7201B | 12 | 32 | 10 | 7.9 | 3.85 | 0.038 |
| 7202B | 15 | 35 | 11 | 8065 | 4.55 | 0.048 |
| 7203AC | 17 | 40 | 12 | 10.9 | 5.9 | 0.07 |
| 7204AC | 20 | 47 | 14 | 15.5 | 9 | 0.112 |
| 7204B | 20 | 47 | 14 | 15.5 | 9 | 0.112 |
| 7205C | 25 | 52 | 15 | 16.6 | 10.2 | 0.135 |
| 7205B | 25 | 52 | 15 | 16.6 | 10.2 | 0.135 |
| 7206C | 30 | 62 | 16 | 23 | 14.7 | 0.208 |
| 7206AC | 30 | 62 | 16 | 23 | 14.7 | 0.208 |
| 7206B | 30 | 62 | 16 | 23 | 14.7 | 0.208 |
| 7207C | 35 | 72 | 17 | 30.4 | 20.1 | 0.295 |
| 7207AC | 35 | 72 | 17 | 30.4 | 20.1 | 0.295 |
| 7207B | 35 | 72 | 17 | 30.4 | 20.1 | 0.295 |
| 7208C | 40 | 80 | 18 | 36.4 | 25.2 | 0.382 |
| 7208AC | 40 | 80 | 18 | 33.6 | 23.3 | 0.382 |
| 7208B | 40 | 80 | 18 | 30.6 | 21.3 | 0.382 |
| 7209C | 45 | 85 | 19 | 40.8 | 28.7 | 0.43 |
| 7210AC | 50 | 90 | 20 | 37.535.7 | 26.7 | 0.485 |
Angular contact ball bearing 7217 type:
Angular contact ball bearings are: 7000 c (∝ = 15 °) and 7000 ac type (∝ = 25 °) and 7000 b (∝ = 40 °) several types.
Bearing 7217 Installation techniques
High speed precision angular contact ball bearing 7207, mainly used for high speed rotating load lighter, bearings and high precision, high speed, low temperature rise, low vibration and service life. Often for high speed motorized spindle bearing parts installed in pairs, is the key to the high-speed motorized spindle surface grinding machine fittings.
Main technical indicators:
1. The bearing precision index: more than GB / 307.1 94 P4 level accuracy
2. High speed performance indicators: the dmN value 1.3 ~ 1.8 x 106 / min
3. The service life of the (average) : > 1500 h
