Gear box bearing gear reducer Cylindrical roller bearings without an inner ring

Gear box bearing gear reducer Cylindrical roller bearings without an inner ring RNU305

RNU305 Cylindrical roller bearings without an inner ring can be used to run directly on a shaft or they can be matched with inner rings with extended width. Such bearings are best suited for the support of oscillating rollers.

Technical data of RNU305

Fw: 35 mm

OD: 62 mm

Width: 17 mm

Weight: 0.17 kg

Basic dynamic load rating: 28.6 kN

Basic static load rating: 15 kN

Fatigue load limit: 3.05 kN

Reference speed: 12000 rpm

Limiting speed: 15000 rpm
