F800 Mud Pump bearing Cross head Bearing Oil field Bearing 5G254735Q

F800 Mud Pump bearing Cross head Bearing Oil field Bearing 5G254735Q

   Old Model            New Model                                           Dimension                           Weight

F500    Crosshead bearing    5G354920Q    NNAL6/101.6Q4/            C5W33XYA2    171.45    101.6    133.35        13.5

F800    Crosshead bearing    5G254735Q    NNAL6/177.8-1Q4/         C5W33XYA2    244.475    177.8    161.925    23.6

F1000    Crosshead bearing    5G254936Q    NNAL6/177.8-2Q4/       C5W33XYA2    257.175    177.8    196.85    34.2

F1300    Crosshead bearing    254941QU    NNAL6/206.375Q4/         W33XYA2    285.75    206.375    222.25    44.9

F1600    Crosshead bearing    254941QU    NNAL6/206.375Q4/         W33XYA2    285.75    206.375    222.25    44.9

F2200    Crosshead bearing    4G154946Q    NNAL6/230Q4/C4YA2                             340     230              206         67.7
