F*A*G Self aligning ball bearing 2206
Self-aligning ball bearings 2206-2RS-TVH have contact lip seals on both sides. Their cages are made from glass fibre reinforced polyamide 66,which character low low weight, lower friction and resistance to corrosion. Sealed 2206-2RS-TVH bearings are greased with a high quality grease and are maintenance-free
Technical data of 2206-2RS-TVH (2206.2RS.TV)
ID: 30 mm
OD: 62 mm
Width: 20 mm
Weight: 0.274 kg
Basic dynamic load rating: 15.9 kN
Basic static load rating: 4.6 kN
Fatigue limit load: 0.285 kN
Limiting speed: 8000 rpm
Description
| 1200 Series | ||
| ITEM | MASS (kg) | D× d × B |
| 1206 | 0.22 | 30×62×16 |
| 1206K | O.22 | |
| 1207 | O.31 | 35×72×17 |
| 1207K | O.32 | |
| 1207TN1 | 0.31 | |
| 1207KTN1 | 0.32 | |
| 1208 | 0.41 | 40×80×18 |
| 1208K | 0.41 | |
| 1208TN1 | 0.4 | |
| 1209 | O.46 | 45×85×19 |
| 1209K | 0.46 | |
| 1209TN1 | 0.46 | |
| 1210 | 0.54 | 50×90×20 |
| 1210K | O.53 | |
| 1210TN1 | 0.54 | |
| 1210KTN1 | 0.53 | |
| 1211 | 0.72 | 55×l00×21 |
| 1211K | O.70 | |
| 1212 | O.86 | 60×l10×22 |
| 1212K | 0.87 | |
| 1213 | 0.91 | 65×120×23 |
| 1213K | 1.15 | |
| 1213TN1 | 0.883 | |
| 1213KTN1 | 0.878 | |
| 1214 | 1.29 | 70×125×24 |
| 1214K | 1.26 | |
| 1215 | 1.35 | 75×130×25 |
| 1215K | 1.35 | |
| 1216 | 1.65 | 80×140×26 |
| 1216K | 1.59 | |
| 1217 | 2.1 | 85×150×28 |
| 1217K | 2.07 | |
| 1218 | 2,51 | 90×160×30 |
| 1218K | 2.5 | |
| 1219 | 3.06 | 95×170×32 |
| 1219K | 3.02 | |
| 1220 | 3.7 | 100×180×34 |
| 1220K | 3.7 | |
| 1221M | 4.71 | 105×190×36 |
| 1222 | 5.2 | 110×200×38 |
| 1222K | 5.12 | |
| 11224J | 5.96 | 120×215×42/45 |
| 11224KJ | 5.9 | |
| 2200 Series | ||
| ITEM | MASS (kg) | D× d × B |
| 2206 | 0.26 | 30×62×20 |
| 2206K | O.25 | |
| 2207 | O.44 | 35×72×23 |
| 2207K | 0.4 | |
| 2208 | 0.53 | 40×80×23 |
| 2208K | 0.52 | |
| 2209 | 0.55 | 45×85×23 |
| 2209K | 0.55 | |
| 2209KTN1 | 0.493 | |
| 2210 | 0.62 | 50×90×23 |
| 2210TN1 | 0.567 | |
| 2210K | O.60 | |
| 2211 | 0.82 | 55×l00×25 |
| 2211K | 0.81 | |
| 2212 | 1.16 | 60×110×28 |
| 2212TN1 | 1.09 | |
| 2212K | 1.14 | |
| 2212KTN1 | 1.07 | |
| 2213 | 1.5 | 65×120×31 |
| 2213K | 1.46 | |
| 2214 | 1.63 | 70×125×31 |
| 2214K | 1.63r>> | |
