CF Camrol series steel stud-type cam follower bearing with lip seals and a hexagonal hole supports high static and dynamic loads in cam- and track-type applications. This precision cam follower has a thick-walled outer ring that helps minimize deformation under heavy radial and shock loads. It has a threaded stud-type design for through-hole or threaded mounting, and a hexagonal hole on the flange end that provides greater holding power during mounting than a screwdriver slot. The inner stud has inch threads manufactured to class 2 tolerances. This cam follower is made of bearing steel treated with black oxide for corrosion protection. The working surfaces of the inner raceways and flange are zone-hardened to support contact stresses from the rolling elements, and the inner ring is ductile to help absorb shock loads
1.Guiding system of rollers
Cam Followers come in types with cages as well as full complement. Bearings with cages are suitable for places having small friction resistance and high-speed revolution, and bearings having full complement are suitable for places having low-speed revolution and places where heavy load is added.
2.Structure of seal portion
Cam Followers come in shield type and sealed type. The shield-type bearings make the gaps between the outer ring and the stud collar portion as well as the outer ring and the side plate portion small and form labyrinths. Sealed-type bearings have a hermetic seal built into the labyrinth portion of the shield type, and entry of foreign matters can be prevented.
3.Shape of outer ring outside Diameter Surface
Since the outer ring of the Cam Follower is used by letting it come into contact directly with the opposing track surface, there are spherical surface and cylindrical surface for the outside diameter of the outer ring. Bearings of spherical outer rings are effective in alleviating the end load based on attachment errors. Furthermore, bearings of cylindrical outer rings have large contact area with the opposing track surface so it is suitable for cases in which the load is large or the hardness of the track surface is low.
stud type track roller bearing CF30-2UU CF30-2UUR
Name | Curve Roller Bearing |
Brand | |
Precision | P4, P5 |
Quality standard | ISO9001:2000 standard |
Service | OEM service |
Delivery date | Normally ready goods and stock |
Payment terms | A: 100% L/C at sight B: 30% T/T in advance , 70% against copy of B/L C: Western Union D: Paypal |
Application | automotive, rolling mill, mining, metallurgical, plastic machinery,etc. |
Package | a. According to customer's requirements. b. Original good quality packaging. c. Laser mark on the bearing. d. Bearing wrapped by vacuum packaging. e. The outer is color polybag + box + carton, industrial standard packaging. |
