32209 JR
KOYO
32209 JR
32209JR Tapered roller bearing in rich stock - KOYO bearing 32209
Specification: 32209JR Tapered roller bearing
Model: 32209 JR
Inner diameter(d): 45mm
Outer diameter(D): 85mm
Thickness(T): 24.75mm
Mass(W): 0.58kg
Calculation date:
Dynamic load rating: 98.7KN
Static load rating: 98KN
Reference speed: 6300r/min
Limiting speed: 8000r/min
Contact: Whatsapp: +86-17854271903; Email: koyo@chinakmbearing.com
Applications of bearing
In many applications tapered roller bearings are used in back-to-back pairs so that axial forces can be supported equally in either direction.
1. Pairs of tapered roller bearings are used in car and vehicle wheel bearings.
2. Common real world applications are in agriculture, construction and mining equipment, sports robot combat, axle systems, gear box, engine motors and reducers, propeller shaft, railroad axle-box, differential, wind turbines, etc.
Our company also can provide other bearings for you!
Model | Inner(mm) | Outer(mm) | Width(mm) | Mass(kg) |
32203 | 17 | 40 | 17.25 | 0.105 |
32204 | 20 | 47 | 19.25 | 0.16 |
32205 | 25 | 52 | 19.25 | 0.19 |
32206 | 30 | 62 | 21.25 | 0.29 |
32207 | 35 | 72 | 24.25 | 0.44 |
32208 | 40 | 80 | 24.75 | 0.53 |
32209 | 45 | 85 | 24.75 | 0.58 |
32210 | 50 | 90 | 24.75 | 0.62 |
32211 | 55 | 100 | 26.75 | 0.84 |
32212 | 60 | 100 | 29.75 | 1.15 |
32213 | 65 | 120 | 32.75 | 1.51 |
32214 | 70 | 125 | 33.25 | 1.6 |
32215 | 75 | 130 | 33.25 | 1.67 |
32216 | 80 | 140 | 35.25 | 2.06 |
32217 | 85 | 150 | 38.5 | 2.61 |
32218 | 90 | 160 | 42.5 | 3.33 |
32219 | 95 | 170 | 45.5 | 4.09 |
32220 | 100 | 180 | 49 | 4.93 |
32221 | 105 | 190 | 53 | 6.02 |
32222 | 110 | 200 | 56 | 7.09 |
32224 | 120 | 215 | 61.5 | 9.05 |
32226 | 130 | 230 | 67.75 | 11.2 |
32228 | 140 | 250 | 71.75 | 14.2 |
32230 | 160 | 270 | 77 | 17.9 |
32232 | 160 | 290 | 84 | 23.2 |
32234 | 170 | 310 | 91 | 28.6 |
32236 | 180 | 320 | 91 | 29.5 |
32238 | 190 | 340 | 97 | 36 |
32240 | 200 | 360 | 104 | 42.4 |
