32224A
Taper roller bearing distributor for cement plant 32224A
Technical data of 32224A
Cone Bore=120 mm
Cup Outer Diameter=215 mm
Bearing Width=61.5 mm
Cone Width=58 mm
Cup Width=50 mm
Weight=9.3 kg
Basic dynamic load rating=485000 N
Basic static load rating= 730000 N
Fatigue limit load=81000 N
Limiting speed=3150 rpm
Reference speed=2120 rpm
Comparative designation to DIN ISO 355: T4FD120
Country of Origin: Germany
322..series original Tapered roller bearings catalogue
Part No. | ID mm | OD mm | Thk mm |
32203-A | 17 | 40 | 17,25 |
32205-A | 25 | 52 | 19,25 |
32206-A | 30 | 62 | 21,25 |
32207-A | 35 | 72 | 24,25 |
32208-A | 40 | 80 | 24,75 |
32209-A | 45 | 85 | 24,75 |
32210-A | 50 | 90 | 24,75 |
32211-A | 55 | 100 | 26,75 |
32212-A | 60 | 110 | 29,75 |
32213-A | 65 | 120 | 32,75 |
32214-A | 70 | 125 | 33,25 |
32215-A | 75 | 130 | 33,25 |
32216-A | 80 | 140 | 35,25 |
32217-A | 85 | 150 | 38,5 |
32218-A | 90 | 160 | 42,5 |
32219-A | 95 | 170 | 45,5 |
32220-A | 100 | 180 | 49 |
32221-XL | 105 | 190 | 53 |
32222-A | 110 | 200 | 56 |
32224-A | 120 | 215 | 61,5 |
32226-A | 130 | 230 | 67,75 |
32228-A | 140 | 250 | 71,75 |
32230-A | 150 | 270 | 77 |
32232-A | 160 | 290 | 84 |
32234-A | 170 | 310 | 91 |
32236-A | 180 | 320 | 91 |
32238-A | 190 | 340 | 97 |
32240-A | 200 | 360 | 104 |
32244-A | 220 | 400 | 114 |
32248-A | 240 | 440 | 127 |
32252 | 260 | 480 | 137 |
32264 | 320 | 580 | 159 |
