Shielded Deep Groove Ball Bearing 15x35x11mm 6202-2Z
You are here: Home » Products » Deep groove ball bearing » Shielded Deep Groove Ball Bearing 15x35x11mm 6202-2Z

Product Detail

Share to:

Shielded Deep Groove Ball Bearing 15x35x11mm 6202-2Z

Shielded Deep Groove Ball Bearing
Quantity:
  • 6202-2Z
Product Description
Single row deep groove ball bearing with two metal shields 15mm inside x 35mm outside x 11mm width, also known as 6202ZZ, 6202Z, 62022ZR, 6202ZR, 62022ZR, 6202ZZE
Single row deep groove ball bearings are used in a wide variety of applications, they are simple in design, non-separable, suitable for high speeds and are robust in operation, and need little maintenance. Deep raceway grooves and the close conformity between the raceway grooves and the balls enable deep groove ball bearings to accommodate axial loads in both directions, in addition to radial loads.
Product Name
6202-2Z
Dimension
15x35x11mm
Speed Ratings

Reference speed
43000 r/min
Limiting speed
22000 r/min
Weight
0.04KGS
Using Effects
Single row deep groove ball bearings are manufactured as open type (unsealed), sealed and shielded, the most popular sizes of deep groove ball bearings are also produced in sealed versions with shields or contact seals on one or both sides, the bearings with shields or seals on both sides are lubricated for life and are maintenance free. A sealed bearings seals has contact on the bearings inner and outer, a shielded bearings shield has contact on the outer only, and Shielded bearings are primarily intended for applications where the inner ring rotates. If the outer ring rotates, there is a risk that the grease will leak from the bearing at high speeds.
