NSK Self-aligning ball bearing 2215 ETN9

  NSK Self-aligning ball bearing 2215 ETN9

2215 ETN9 Self-aligning ball bearings are consequently self-aligning and insensitive to angular misalignments of the shaft relative to the housing. It is particularly suitable for applications where considerable shaft deflections or misalignment are to be expected. Additionally, the self-aligning ball bearing has the lowest friction of all rolling bearings, which enables it to run cooler even at high speeds.

Technical data of bearings 2215 ETN9

ID: 75 mm

OD: 130 mm

Width: 31 mm

Weight; 1.60 kg

Basic dynamic load rating: 58.5 kN

Basic static load rating: 22 kN

Fatigue load limit: 1.12 kN

Reference speed: 9000 rpm

Limiting speed: 6300 rpm
